Shure ULX4 / Beta 58A 2 Handheld (Hitam), harga Rp. 1.650.000,-
Shure ULX4 / Beta 58A 2 Handheld (Putih), harga Rp. 1.850.000,-
KAMI MENJUAL BARANG ECERAN DENGAN HARGA GROSIR
HARGA YANG KAMI CANTUMKAN BELUM TERMASUK ONGKOS KIRIM
System technical specifications
- Compatible systems per frequency band: 40
- Auto Setup Features: Scan/Group Scan
- Audio Reference Companding: Yes
- Included Antennas: Remotable 1/2-wave
- Antenna Options: Yes
- PC Control: No
- Receiver Network Ability: No
- Rack Hardware: Included
- Case: Optional System Case
- Transmitter Display: Backlit multi-function LCD + LED
- Receiver Display: Backlit multi-function LCD + LED
- Battery, Endurance: 9V, > 8 h
- Environment: Performance and professional touring
Further Technical Specs
ULXP4 Receiver:
RF Carrier Frequency Range*
470.000 – 865.000 MHz
*Note: Frequencies above 698.000 MHz are for use outside of the U.S. Contact your local dealer, distributor or Shure for more information.
Effective Range
100 m (300 ft.) under optimal conditions
NOTE: Actual working range depends on RF signal absorption, reflection, and interference
Audio Frequency Response
25 to 15,000 Hz, ±2 dB
NOTE: Overall system frequency response depends on the microphone element.
*Output Level: Microphone Level = Line Level – 20 dB
Transmitter Audio Polarity
Positive pressure on microphone diaphragm (or positive voltage applied to tip of WA302 phone plug) produces positive voltage on pin 2 (with respect to pin 3 of low impedance output) and the tip of the high impedance 1/4-inch output
Transmitter Gain Adjustment Range
ULX1: 25 dB
ULX2: 25 dB
Receiver Audio Output Level (±38 kHz deviation, 1 kHz tone)
XLR connector (into 600 ohm load): +3.9 dBV (line), –17 dBV (mic)
1/4 inch connector (into 3000 ohm load): –2 dBV
Impedance
ULX1 (input): 1 Megohm
ULXP4 (output): 50 ohms at line level; 2000 ohms at mic level
Modulation
±38 kHz deviation compressor-expander system with pre- and de-emphasis.
RF Power Output
ULX1, ULX2: 30 mW maximum
Dynamic Range
>100 dB, A-weighted
RF Sensitivity
1.26 μV for 12 dB SINAD (typical)
Image Rejection
80 dB typical
Spurious Rejection
75 dB typical
Ultimate Quieting (reference ±38 kHz deviation)
>105 dB, A-weighted
System Distortion (reference ±38 kHz deviation, 1 kHz modulation)
0.3% total harmonic distortion, typical
Power Requirements
ULX1, ULX2: 9V alkaline battery (Duracell MN1604 recommended); 8.4V Nicad optional
ULXP4: 14 - 18 Vdc (negative ground), 550 mA
Battery Life
8 to 9 hours (with 9V Duracell MN1604 alkaline battery)
Operating Temperature Range
-20° to 49° C (–4° to 120° F)
ULXP4 Receiver:
RF Carrier Frequency Range*
470.000 – 865.000 MHz
*Note: Frequencies above 698.000 MHz are for use outside of the U.S. Contact your local dealer, distributor or Shure for more information.
Effective Range
100 m (300 ft.) under optimal conditions
NOTE: Actual working range depends on RF signal absorption, reflection, and interference
Audio Frequency Response
25 to 15,000 Hz, ±2 dB
NOTE: Overall system frequency response depends on the microphone element.
*Output Level: Microphone Level = Line Level – 20 dB
Transmitter Audio Polarity
Positive pressure on microphone diaphragm (or positive voltage applied to tip of WA302 phone plug) produces positive voltage on pin 2 (with respect to pin 3 of low impedance output) and the tip of the high impedance 1/4-inch output
Transmitter Gain Adjustment Range
ULX1: 25 dB
ULX2: 25 dB
Receiver Audio Output Level (±38 kHz deviation, 1 kHz tone)
XLR connector (into 600 ohm load): +3.9 dBV (line), –17 dBV (mic)
1/4 inch connector (into 3000 ohm load): –2 dBV
Impedance
ULX1 (input): 1 Megohm
ULXP4 (output): 50 ohms at line level; 2000 ohms at mic level
Modulation
±38 kHz deviation compressor-expander system with pre- and de-emphasis.
RF Power Output
ULX1, ULX2: 30 mW maximum
Dynamic Range
>100 dB, A-weighted
RF Sensitivity
1.26 μV for 12 dB SINAD (typical)
Image Rejection
80 dB typical
Spurious Rejection
75 dB typical
Ultimate Quieting (reference ±38 kHz deviation)
>105 dB, A-weighted
System Distortion (reference ±38 kHz deviation, 1 kHz modulation)
0.3% total harmonic distortion, typical
Power Requirements
ULX1, ULX2: 9V alkaline battery (Duracell MN1604 recommended); 8.4V Nicad optional
ULXP4: 14 - 18 Vdc (negative ground), 550 mA
Battery Life
8 to 9 hours (with 9V Duracell MN1604 alkaline battery)
Operating Temperature Range
-20° to 49° C (–4° to 120° F)
Shure ULX4 2 ClipOn / Headset
Mic ULX4 ini merupakan mic yang sangat professional & konsekuen dalam penanganan jarak transmitter. Selain suara yang nan lembut & ngeri, jangkauan mic ini bisa mencapai 70 - 80m. Mempnyai fitur yang canggih total. Selain 2 volume master besar di bagian kanan receiver, terdapat juga volume tambahan guna membuat kompressan mic menjadi lebih takjub. Tersedia juga mic yang bewarna putih. Bodypack transmitter menghasilkan suara yang lebih powerfull ketika mengolah teknik vokal
Shure ULX4 2 ClipOn / Headset, harga Rp. 2.000.000,-
KAMI MENJUAL BARANG ECERAN DENGAN HARGA GROSIR
HARGA YANG KAMI CANTUMKAN BELUM TERMASUK ONGKOS KIRIM
System technical specifications
- Compatible systems per frequency band: 40
- Auto Setup Features: Scan/Group Scan
- Audio Reference Companding: Yes
- Included Antennas: Remotable 1/2-wave
- Antenna Options: Yes
- PC Control: No
- Receiver Network Ability: No
- Rack Hardware: Included
- Case: Optional System Case
- Transmitter Display: Backlit multi-function LCD + LED
- Receiver Display: Backlit multi-function LCD + LED
- Battery, Endurance: 9V, > 8 h
- Environment: Performance and professional touring
Further Technical Specs
ULXP4 Receiver:
RF Carrier Frequency Range*
470.000 – 865.000 MHz
*Note: Frequencies above 698.000 MHz are for use outside of the U.S. Contact your local dealer, distributor or Shure for more information.
Effective Range
100 m (300 ft.) under optimal conditions
NOTE: Actual working range depends on RF signal absorption, reflection, and interference
Audio Frequency Response
25 to 15,000 Hz, ±2 dB
NOTE: Overall system frequency response depends on the microphone element.
*Output Level: Microphone Level = Line Level – 20 dB
Transmitter Audio Polarity
Positive pressure on microphone diaphragm (or positive voltage applied to tip of WA302 phone plug) produces positive voltage on pin 2 (with respect to pin 3 of low impedance output) and the tip of the high impedance 1/4-inch output
Transmitter Gain Adjustment Range
ULX1: 25 dB
ULX2: 25 dB
Receiver Audio Output Level (±38 kHz deviation, 1 kHz tone)
XLR connector (into 600 ohm load): +3.9 dBV (line), –17 dBV (mic)
1/4 inch connector (into 3000 ohm load): –2 dBV
Impedance
ULX1 (input): 1 Megohm
ULXP4 (output): 50 ohms at line level; 2000 ohms at mic level
Modulation
±38 kHz deviation compressor-expander system with pre- and de-emphasis.
RF Power Output
ULX1, ULX2: 30 mW maximum
Dynamic Range
>100 dB, A-weighted
RF Sensitivity
1.26 μV for 12 dB SINAD (typical)
Image Rejection
80 dB typical
Spurious Rejection
75 dB typical
Ultimate Quieting (reference ±38 kHz deviation)
>105 dB, A-weighted
System Distortion (reference ±38 kHz deviation, 1 kHz modulation)
0.3% total harmonic distortion, typical
Power Requirements
ULX1, ULX2: 9V alkaline battery (Duracell MN1604 recommended); 8.4V Nicad optional
ULXP4: 14 - 18 Vdc (negative ground), 550 mA
Battery Life
8 to 9 hours (with 9V Duracell MN1604 alkaline battery)
Operating Temperature Range
-20° to 49° C (–4° to 120° F)
